Watchdog Timer

Built-in Nvidia Orin Module

System Memory

NX 16GB / NX 8GB / Nano 8GB / Nano 4GB 128-bit LPDDR5

Processor

NVIDIA ARM Cortex-A78AE v8.2 64-bit CPU, NVIDIA Ampere architecture with 1024/512 cores and 32 Tensor cores GPU

M.2

M.2 E-key socket*1 for 2230 WIFI/BT module; M.2 B-key socket*1 for 3042/3052 5G module

M.2

128GB M.2 2280 NVMe SSD

Ethernet Interface

2 x RJ-45 10/100/1000 Mbps Ethernet

OS

Linux Ubuntu 20.04

Certification Information

CE, FCC Class A

USB

4 x USB3.1 Type A

COM

2 x COM (switch by Jumper to RS-232 or RS485) 1 x CAN BUS (optional)

Display

1 x HDMI Type A

Power Requirement

DC 10~24V Terminal Block 2 pin
DC 10~36V (optional)

Dimension (W x L x H)

125mm*196mm*66.1mm (w/o wall mount bracket)

Weight

1.4 kg

Operating Temp.

-20°C ~ 60°C, (-4°F ~ 140°F) according to IEC60068-2 with 0.5 m/s AirFlow

Storage Temp.

-40°C ~ 80°C, (-40°F ~ 176°F)

Operating Humidity

40°C @ 95% Relative Humidity, Non-condensing

Construction

Aluminum extrusion and heavy-duty steel

Mounting Kit

Wall Mount Bracket (Optional)

Ordering Information

AIB-NW01-NA04-A1R : AIB-NW01-NA04-A1R
AIB-NW01-NA08-A1R : AIB-NW01-NA08-A1R
AIB-NW01-NX08-A1R : AIB-NW01-NX08-A1R
AIB-NW01-NX16-A1R : AIB-NW01-NX16-A1R
