RITY152

15” XGA Flat Touch Panel PC Intel® Atom™ Processor with Intel® Valleyview SoC

Get a Quote

Comparison

Datasheet

Get a Quote

Comparison

Datasheet

  • Specification
  • Document
  • FAQ

ProductSpecification

System Information

  • Processor

    Intel® Atom™ E3845 4-Core 1.91GHz processor

  • Platform Controller Hub

    Intel® Valleyview SoC

  • System Memory

    1 x 204-pin DDR3L 1066MHz SO-DIMMup to 8 GB

  • I/O Chipset

    EC ITE IT8528E

  • Watchdog Timer

    H/W reset, 1sec. ~ 65535sec. and 1sec./step

  • H/W Status Monitor

    Monitoring CPU & system temperature and voltage

  • SBC

    APC-BYTPOS

Expansion

  • Expansion

    1 x Mini PCIe supports mSATA

Storage

  • Storage

    1 x 2.5 Drive bay
    1 x mSATA

Display

  • Graphic Chipset

    Intel® Valleyview SoC integrated Graphics
    Supports dual display

  • Spec. & Resolution

    LVDS:Max. resolution 1024x768@ 60Hz
    HDMI:Max. resolution 1920x1080@ 60Hz

Audio

  • Audio Codec

    Realtek ALC888S supports 2-CH

  • Audio Interface

    Line-out

  • Speaker Output

    2 x 2W

Ethernet

  • LAN Chipset

    2 x Realtek 8111E

  • Ethernet Interface

    10/100/1000 Base-Tx GbE compatible

Power Requirement

  • DC Input

    +19V ~ +24V

  • DC Input Connector

    minidin 4P for DC in w/ lock type

Software Support

  • OS

    Win 7 / Win 8 / POS ready

Certification

  • Certification Information

    CE
    FCC Class B
    VCCI

External I/O

  • USB

    3 x USB 3.0
    3 x USB 2.0

  • LAN Port

    2 x RJ-45

Panel

  • LCD Size

    15", 4:3

  • Display Type

    XGA

  • Resolution

    1024 x 768

  • Pixel pitch

    16.2M

  • Luminance

    400 cd/m2

  • Contrast ratio

    700

  • Viewing angle

    80(H) X 70(V)

  • Response time

    8 ms

  • Backlight

    LED

  • Touch Type

    5 wires resistive / PCT

  • Touch Light Transmission

    RES 75% / PCT 90%

  • Touch Controller

    Onboard USB touch (penmount) / USB touch (EETI)

I/O

  • COM Port

    2 x RS-232/422/485 (BIOS)
    1 x RS-232

Mechanical & Environmental

  • Operating Temp.

    0°C ~ 35°C (32°F ~ 95°F)

  • Storage Temp.

    -10°C ~ 60°C (14°F ~ 140°F)

  • Operating Humidity

    0% ~ 90% Relative humidity, non-condensing

  • Dimension (W x L x H)

    362.1 X 290.08 X 51 mm

  • Weight

    6 Kg /with stand

  • Vibration Test

    With SSD/mSATA : 1.5Grms, IEC 60068-2-64, random, 5 ~ 500Hz, 30min/axis

  • Shock Test

    With CF/SSD : 10Grms, IEC 60068-2-27, half sine, 11ms

  • Power Mode

    AT/ATX (ATX is default setting)

  • System Fan

    Fanless

  • Construction - Front

    Black coverlens

  • Construction - Rear

    Black

Component

  • Adapter

    Input: 100 ~ 240Vac/ 50 ~ 60Hz
    Output: 90W adapter (24V @ 3.75A adapter)

  • BIOS
    4
  • Chipset
    2
  • Audio
    2
  • Graphics
    6
  • LAN
    2
  • Drawing
    3
  • Manual
    1
  • Other Driver
    13
  • All
  • Windows 10 64bit
  • Windows 8 64bit
  • Windows 8 32bit
  • Windows 7 64bit
  • Windows CE
  • BIOS

    Total 4 Files

    No.
    Release Date
    Title、Description
    Operating System
    Document
    Download
    2023-11-01
    RIT152J3)RITY122/152(J1900) 1.20CS:FEB4H,P/N:E1512RT2205R
    • N/A
    2023-11-01
    (RITY1229)RITY122/152 BIOS 1.20 CS:E6A9H,P/N:E1512RT2204R
    • N/A
    2023-11-01
    RIT152J2)RITY122/152(J1900) 1.10CS:8E73H,P/N:E1512RT2203R
    • N/A
    2023-11-01
    (RITY1228)RITY122/152 BIOS 1.10 CS:61BEH,P/N:E1512RT2202R
    • N/A

    OPEN ALL FILES

    Chipset

    Total 2 Files

    No.
    Release Date
    Title、Description
    Operating System
    Document
    Download
    2023-11-01
    Intel_Chipset_D1_Win10_64
    • Windows 10 64bit
    2023-11-01
    Intel Chipset Win 7 8 10 32_64
    • Windows CE
    • Windows 7 64bit
    • Windows 8 64bit
    • Windows 8 32bit
    • Windows 10 64bit

    Audio

    Total 2 Files

    No.
    Release Date
    Title、Description
    Operating System
    Document
    Download
    2023-11-01
    Realtek ALC892 Win 7 8 10_64
    • Windows 7 64bit
    • Windows 8 64bit
    • Windows 10 64bit
    2023-11-01
    Realtek ALC892 Win 7 8_32
    • Windows CE
    • Windows 8 32bit

    Graphics

    Total 6 Files

    No.
    Release Date
    Title、Description
    Operating System
    Document
    Download
    2023-11-01
    Intel_Graphics_D1_Win10_64
    • Windows 10 64bit
    2023-11-01
    Intel VGA Win 10_64
    • Windows 10 64bit
    2023-11-01
    Intel HD Graphic Win8 64
    • Windows 8 64bit
    2023-11-01
    Intel HD Graphic Win8 32
    • Windows 8 32bit
    2023-11-01
    Intel EMGD Win7 64
    • Windows 7 64bit
    2023-11-01
    Intel EMGD Win7 32
    • Windows CE

    OPEN ALL FILES

    LAN

    Total 2 Files

    No.
    Release Date
    Title、Description
    Operating System
    Document
    Download
    2023-11-01
    Realtek RTL811x Win 8 10_32 64
    • Windows 8 64bit
    • Windows 8 32bit
    • Windows 10 64bit
    2023-11-01
    Realtek RTL811x Win 7 32_64
    • Windows CE
    • Windows 7 64bit

    Drawing

    Total 3 Files

    No.
    Release Date
    Title、Description
    Operating System
    Document
    Download
    2023-11-01
    RITY152 system drawing with stand and VFD
    • N/A
    2023-11-01
    RITY152 system drawing with stand
    • N/A
    2023-11-01
    RITY152 system drawing without stand
    • N/A

    Manual

    Total 1 Files

    No.
    Release Date
    Title、Description
    Operating System
    Document
    Download
    2023-11-01
    Rity152 1st Quick Reference Guide
    • N/A

    Other Driver

    Total 13 Files

    No.
    Release Date
    Title、Description
    Operating System
    Document
    Download
    2023-11-01
    SMSC_Prolink_MPT
    • Windows 10 64bit
    2023-11-01
    Intel_TXE_D1_Win10_64
    • Windows 10 64bit
    2023-11-01
    Intel_MBI_D1_Win10_64
    • Windows 10 64bit
    2023-11-01
    Intel MBI Win 10_64
    • Windows 10 64bit
    2023-11-01
    Intel TXE Win 10_64
    • Windows 10 64bit
    2023-11-01
    Penmount 6000 Win 7 8 10_32 64
    • Windows CE
    • Windows 7 64bit
    • Windows 8 32bit
    • Windows 8 64bit
    • Windows 10 64bit
    2023-11-01
    Intel MBI driver
    • Windows 8 64bit
    • Windows 8 32bit
    2023-11-01
    Intel TXE dirver hotfix
    • Windows 7 64bit
    2023-11-01
    Intel TXE driver hotfix
    • Windows CE
    2023-11-01
    Renesas USB3.0 Driver
    • Windows CE
    • Windows 7 64bit
