Speaker Output

2W speaker x2

Certification Information

cTUVus 60601-1;CAN/CSA-C22.2 60601-1
CB(IEC 62368-1，IEC 60601-1),
CE(EN55032;EN55035;EN62368-1, ROHS,WEEE);EN 60601-1-2;
FCC Part15 subpart B

LCD Size

23.8"

Display Type

Full HD

Resolution

1920 x 1080

Pixel pitch

0.2745 mm x 0.2745mm

Luminance

350 cd/m2 (Typ.)

Contrast ratio

3000

Viewing angle

178/178 Deg. Horizontal & Vertical

Response time

14 ms

Backlight

LED

Touch Type

Projective capacitive multi-touch up to 10 points

Display color

16.7 M

DICOM compliant

Yes

Active display area

527.04 mm x 296.46mm

Input Interface

1 x HDMI
1 x Display port

Cables

1 x HDMI cable
1 x DP cable
1 x USB 2.0 cable (for touch)

User control and indicator

Physical button for multi-language OSD & Power indicator*1 :
Brightness, Contrast, Color mode, Audio, Language, Source, Power key lock, Re-set

Operating Temp.

0°C ~ 40°C (32°F ~ 104°F)

Storage Temp.

-20°C ~ 60°C (-4°F ~ 140°F)

Operating Humidity

10% ~ 90% relative humidity, non-condensing

Weight

5.4 Kg

IP Rating

Front IP65 & Rear IPx2

VESA

100 x 100

System Fan

Fanless

Construction

Plastic

Power Requirement

AC/DC Adapter
Input: 100-240Vac, 1.5-0.75A, 50-60 Hz
Output: 12Vdc, 5.0A

Power Mode

12V DC in

Mounting Kit

Stand (optional)
VESA mount kit (optional)
Wall mount kit (optional)

Dimension

571.43mm x 340.9mm x 52.7mm

Base stand

Tilt adjustable (optional)

Color temperature

Cool/neutral/warm/user

Ordering Information

RCC-MS-DIV23T-01R
QD0124CM01/23.8"/1920x1080/PCAP/12V/350nits/1000:1/HDMI/DP
With
1. 65W power adapter x 1
2. HDMI cable x 1
3. DP cable x 1
4. USB 2.0 cable (for touch) x 1
