Avalue Technology - Industrial Computer

Processor

UNISOC T606 Hexa-core Cortex-A55 + Dual-core Cortex-A75

System Memory

Onboard 4GB RAM

Storage

Onboard 64GB eMMC

Graphic Chipset

Mali-G57 MP1 GPU

Speaker Output

Yes

Ethernet Interface

10/100/1000 Base-Tx GbE compatible

DC Input

12V

DC Input Connector

DC Jack

Adapter

Input: 100 ~ 240Vac/ 50 ~ 60Hz​
Output: 24W (12V@2A) AC-DC adapter

OS

Android 14

LCD Size

11" HD Main Screen + 2.4" Customer Facing Display

LCD Panel

IPS

Display Type

LED

Resolution

800 x 1280

Luminance

350 cd/m2

Contrast ratio

1,300

Viewing angle

85/85/85/85 (L/R/U/D)

Response time

25ms

Touch Type

Projective capacitive multi-touch

USB Port

4 x USB 3.0
1 x USB Type-C (Only Support OTG/ADB)

LAN Port

1 x RJ45

Cash Drawer

1 x RJ11
1 x RJ12

Other

2 x SIM Card Slot

Battery Type

Lithium

Typical Capacity

6,400mAh

Control Buttons

Power / Volume+ / Volume- / Scan

Printing Method

Direct Thermal

Total Dots Per Line

576 dots/line

Max. Print Speed

90 mm/s

Max. Print Width

72mm

Max. Paper Width

80mm / 58mm

Resolution

203 dpi

Type of Paper Cutting

Metal Cutter

Media Dimension

Max. Roll Diameter: Ø 60mm).

NFC

Support ISO/IEC 14443 Type A/B, Mifare1, SL3, Felica

Barcode Scanner

1D/2D IR

WLAN

Optional Wi-Fi 802.11b/g/n/ac

Bluetooth

Optional BT 5.0

Operating Temp.

0°C ~ 40°C (32°F ~ 104°F)

Storage Temp.

-20°C ~ 60°C (-4°F ~ 140°F)

Operating Humidity

20~80%RH

Dimension (W x L x H)

261,9 x 280.7 x 112mm

Weight

1.75kg

Packing List

1 x RPC-11NB
1 x 12V/2A Adapter
1 x USB cable
1 x roll 80mm thermal paper
