REV-SA01

3.5 inch SMARC specification compliant

Get a Quote

Comparison

Datasheet

Get a Quote

Comparison

Datasheet

3.5” SBC Form Factor
Accept Avalue and Other SMARC Compatible
1 x Mini-PCIe + SIM Socket
2 x CAN BUS
2 x Gigabit LAN

Specification
Document
FAQ

ProductSpecification

Audio

Audio Codec

Wolfson WM8962

Certification

Certification Information

CE, FCC Class B

I/O

External I/O Connector

1 x DB9
1 x HDMI
1 x Mini-USB
2 x RJ45
2 x USB Type A
1 x VGA
Internal I/O Connector

1 x Backlight
2 x CAN BUS
1 x GPIO
1 x LVDS
1 x RS-232
1 x RTC Battery
1 x SATA
1 x SD Slot
1 x Speaker
1 x USB

Mechanical & Environmental

Operating Temp.

0°C ~ 60°C (32°F ~ 140°F)
Storage Temp.

-20°C ~ 80°C (-40°F ~ 176°F)
Operating Humidity

0% ~ 90% Relative Humidity, Non-condensing
Weight

0.13kg
Power Requirement

DC 9~36V
Power Mode

AT
Dimension (L x W)

146 x 101 mm

Ordering Information

Ordering Information

REV-SA01-03-A1R : REV-SA01-03-A1R

Design Document

2
Manual

1

Design Document

Total 2 Files

No.

Release Date

Title、Description

Operating System

Document

Download

2023-11-01

REV-SA01 3D

2023-11-01

REV-SA01 2D

Manual

Total 1 Files

No.

Release Date

Title、Description

Operating System

Document

Download

2023-11-01

REV-SA01 3rd Manual
