AIB-ROCK28

BOX System with Rockchip RK3288

Get a Quote

Comparison

Datasheet

Get a Quote

Comparison

Datasheet
  • AIB-ROCK28
  • 8GB eMMC
  • CE, FCC
  • Specification
  • Document
  • FAQ

ProductSpecification

System Information

  • Processor

    RockChip RK3288W

  • Platform Controller Hub

    RockChip RK3288W

  • System Memory

    2GB DDR3

  • SBC

    RockChip RK3288W

Storage

  • eMMC

    16GB eMMC

External I/O Connector

  • External I/O Connector

    1 x 10/100/1000 RJ45 Powered LAN
    1 x HDMI
    1 x M.2 3042 B-Key
    1 x Micro SD slot
    3 x RS232
    1 x RS485
    1 x Reset
    4 x USB 2.0 Type A
    1 x Wifi 802.11 b/g/n

Power Requirement

  • Power Requirement

    DC 12~24V

Software Support

  • OS

    Android 8.1 , Debian 9

Certification

  • Certification Information

    CE, FCC Class B

Mechanical & Environmental

  • Operating Temp.

    0°C ~ 40°C (32°F ~ 104°F)

  • Storage Temp.

    -20°C ~ 60°C (-4°F ~ 140°F)

  • Dimension (W x L x H)

    200 x 110 x 43.8 mm

  • Weight

    0.71 kg

Ordering Information

  • Ordering Information

    AIB-ROCK28-A11-1R : AIB-ROCK28-A11-1R

  • Manual
    1
  • All
    •

    Manual

    Total 1 Files

    No.
    Release Date
    Title、Description
    Operating System
    Document
    Download
    2023-11-01
    AIB-ROCK28 1st Quick Reference Guide
