Avalue Technology - Industrial Computer

Processor

Rockchip RK3576S Quad core cortex A53+Quad core cortex A72

System Memory

Onboard 2GB RAM

Storage

Onboard 16GB eMMC

Graphic Chipset

Mali-G52 MC3 GPU

Audio Interface

Built-in Dual Microphone

Speaker Output

2 x 8Ω/2W

Ethernet Interface

10/100/1000 Base-Tx GbE compatible

DC Input

12V or Powered LAN IEEE 802.3at

DC Input Connector

DC Jack

Adapter

Input: 100 ~ 240Vac/ 50 ~ 60Hz​, Output: 18W (12V@1.5A)
(Alternative: Powered LAN IEEE 802.3at)

OS

Android 14

LCD Size

10.1"

Resolution

1280 x 800

Luminance

320 cd/m2

Contrast ratio

1,200

Viewing angle

80/80/80/80 (L/R/U/D)

Response time

25ms

Touch Type

Projective capacitive multi-touch up to 10 points

USB Port

1 x USB 3.0
1 x USB for Seriel (TTL Level)
1 x USB Type-C (Only Support OTG/ADB)

Audio Port

1 x 3.5mm Earphone/Mic Combo Jack

LAN Port

1 x RJ45

Other

1 x Micro SD Card Slot (Supports up to 64GB)

LED Indicator

Four-side Interactive LED Halo Light Bar
(Built-in G-sensor for auto-screen rotation)

Control Buttons

Power

NFC

Optional NXP PN7160

Camera

5MP Camera

WLAN

Optional Wi-Fi 802.11b/g/n/a/ac/ax

Bluetooth

Optional BT 5.4

Operating Temp.

0°C ~ 40°C (32°F ~ 104°F)

Storage Temp.

-20°C ~ 60°C (-4°F ~ 140°F)

Operating Humidity

20~80%RH

Dimension (W x L x H)

212.6 x 148 x 21.9 mm

Weight

0.94kg

VESA

75 x 75mm

Power Mode

AT/ATX (AT is default)

Packing List

1 x RPC-08WA
1 x Wall Mount Kit
1 x 12V/1.5A Adapter
