RPC-43/55WF

43" / 55" Ultra Slim Panel PC with Rockchip RK3576S

Get a Quote

Comparison

Datasheet

Related Tags

Get a Quote

Comparison

Datasheet

Related Tags

  • 43" / 55" FHD (1920x1080) LCD with 10-point PCAP Multi-touch
  • Rockchip RK3576S Quad core cortex A53+Quad core cortex A72
  • 4GB DDR & 32GB eMMC
  • Fanless operation from 0°C ~ 40°C
  • Support Android 14 with Google EDLA
  • Built-in High-Power 5W Speakers & Convenient Side Buttons (Power/Volume)
  • Specification
  • FAQ

ProductSpecification

System Information

  • Processor

    Rockchip RK3576S Quad core cortex A53+Quad core cortex A72

  • System Memory

    Onboard 4GB RAM

Storage

  • Storage

    Onboard 32GB eMMC

Display

  • Graphic Chipset

    Mali-G52 MC3 GPU

Audio

  • Audio Interface

    Built-in Microphone

  • Speaker Output

    2 x 8Ω/5W

Ethernet

  • Ethernet Interface

    10/100/1000 Base-Tx GbE compatible

Power Requirement

  • Power Type

    AC 100~240V

  • Power Connector Type

    IEC C13 socket

Software Support

  • OS

    Android 14

Panel

  • LCD Size

    43WF : 43"
    55WF : 55"

  • Resolution

    1920 x 1080

  • Luminance

    300 cd/m2

  • Contrast ratio

    1,200

  • Viewing angle

    89/89/89/89 (L/R/U/D)

  • Backlight

    30,000h

  • Touch Type

    Projective capacitive multi-touch up to 10 points

External I/O

  • USB Port

    1 x USB 3.0
    1 x USB 2.0
    1 x USB Type-C (USB 3.2 Gen 1, Data & OTG/ADB)

  • LAN Port

    1 x RJ45

  • HDMI

    1 x HDMI-in

System Control

  • Control Buttons

    Power / Volume+ / Volume -

Data Collection

  • Camera

    5MP Camera

Wireless Communication

  • WLAN

    Optional Wi-Fi 802.11b/g/n/a/ac/ax

  • Bluetooth

    Optional BT 5.4

Mechanical & Environmental

  • Operating Temp.

    0°C ~ 40°C (32°F ~ 104°F)

  • Storage Temp.

    -20°C ~ 60°C (-4°F ~ 140°F)

  • Operating Humidity

    20~80%RH

  • Dimension (W x L x H)

    43WF : 995 x 592 x 55.6 mm
    55WF : 1,263 x 747 x 56.5 mm

  • Weight

    43WF : 18.4kg
    55WF : 32.2kg

  • VESA

    400 x 400 mm

  • Power Mode

    AT/ATX (AT is default)

Packing List

  • Packing List

    1 x RPC-43/55WF
    1 x Power Cord
