RITY153

15” XGA Flat Touch Panel PC Intel® Celeron® Processor with Intel® Apollo Lake SoC

  • Specification
  • Document
  • FAQ

ProductSpecification

System Information

  • Processor

    Intel® Celeron® Processor N3350 1.1GHz

  • Platform Controller Hub

    Intel® Apollo Lake SoC

  • System Memory

    1 x 204-pin DDR3L 1066MHz SO-DIMMup to 8 GB

  • I/O Chipset

    EC ITE IT8528E

  • Watchdog Timer

    H/W reset, 1sec. ~ 65535sec. and 1sec./step

  • H/W Status Monitor

    Monitoring CPU & system temperature and voltage

  • Battery

    Support battery pack 4S1P 14.4V (optional)

Expansion

  • Expansion

    1 x M.2 B key slot support

Storage

  • Storage

    1 x 2.5 Drive bay
    1 x M.2 B key slot

Display

  • Graphic Chipset

    Intel® Apollo Lake SoC integrated Graphics
    Supports dual display

  • Spec. & Resolution

    LVDS:Max. resolution 1024x768@ 60Hz
    HDMI:Max. resolution 1920x1080@ 60Hz

Audio

  • Audio Codec

    Realtek ALC888S supports 2-CH

  • Audio Interface

    Line-out

Ethernet

  • LAN Chipset

    2 x Realtek RTL8111E-VB-GR

  • Ethernet Interface

    10/100/1000 Base-Tx GbE compatible

Power Requirement

  • DC Input

    +19V ~ +24V

  • DC Input Connector

    minidin 4P for DC in w/ lock type

Software Support

  • OS

    Win 10

Certification

  • Certification Information

    CE
    FCC Class B
    VCCI

External I/O

  • USB

    4 x USB 3.0
    2 x USB 2.0

  • LAN Port

    2 x RJ-45

Panel

  • LCD Size

    15", 4:3

  • Display Type

    XGA

  • Resolution

    1024 x 768

  • Pixel pitch

    16.2M

  • Luminance

    400 cd/m2

  • Contrast ratio

    700

I/O

  • COM Port

    2 x RS-232/422/485 (BIOS)
    1 x RS-232

  • HDMI

    1 x HDMI 1.4b

Mechanical & Environmental

  • Operating Temp.

    0°C ~ 40°C (32°F ~ 104°F)

  • Storage Temp.

    -10°C ~ 60°C (14°F ~ 140°F)

  • Operating Humidity

    0% ~ 90% Relative humidity, non-condensing

  • Dimension (W x L x H)

    362.1 X 290.08 X 51 mm

  • Weight

    6 Kg /with stand

  • Vibration Test

    With SSD : 1.5Grms, IEC 60068-2-64, random, 5 ~ 500Hz, 30min/axis

  • Shock Test

    With SSD : 10Grms, IEC 60068-2-27, half sine, 11ms

  • Power Mode

    AT/ATX (ATX is default setting)

  • System Fan

    Fanless

  • Construction - Front

    Black coverlens

  • Construction - Rear

    Black

Component

  • Adapter

    Input: 100 ~ 240Vac/ 50 ~ 60Hz
    Output: 90W adapter (24V @ 3.75A adapter)

  • BIOS
    5
  • Chipset
    2
  • Audio
    1
  • Graphics
    2
  • LAN
    1
  • Design Document
    1
  • Manual
    1
  • Other Driver
    6
  • All
  • Windows 10 64bit
  • BIOS

    Total 5 Files

    No.
    Release Date
    Title、Description
    Operating System
    Document
    Download
    2023-11-01
    RTAPLB0M)RITY153(BAT) BIOS 1.10 CS:E0B9H,P/N:E1512RT5304R
    • N/A
    2023-11-01
    (RTAPL00M)RITY153 BIOS 1.30 CS:C048H,P/N:E1512RT5303R
    • N/A
    2023-11-01
    RTAPLB0K)RITY153(BAT) BIOS 1.00 CS:9098H,P/N:E1512RT5302R
    • N/A
    2023-11-01
    (RTAPL00K)RITY153 BIOS 1.20 CS:EF31H,P/N:E1512RT5301R
    • N/A
    2023-11-01
    (RTAPL00H)RITY153 BIOS 1.00 CS:063FH,P/N:E1512RT5300R.
    • N/A

    OPEN ALL FILES

    Chipset

    Total 2 Files

    No.
    Release Date
    Title、Description
    Operating System
    Document
    Download
    2023-11-01
    Intel_APL_Chipset_Win10_64_10.1.17969.8134_19H1
    • N/A
    2023-11-01
    Intel_APL_Chipset_Win10_64_10.1.1.35
    • Windows 10 64bit

    Audio

    Total 1 Files

    No.
    Release Date
    Title、Description
    Operating System
    Document
    Download
    2023-11-01
    Realtek_ALC892_Audio_Win10_64_R279
    • N/A

    Graphics

    Total 2 Files

    No.
    Release Date
    Title、Description
    Operating System
    Document
    Download
    2023-11-01
    Intel_APL_VGA_Win10_64_26.20.100.7157_19H1
    • N/A
    2023-11-01
    Intel_APL_VGA_Win10_64_21.20.16.4550
    • Windows 10 64bit

    LAN

    Total 1 Files

    No.
    Release Date
    Title、Description
    Operating System
    Document
    Download
    2023-11-01
    Realtek_Lan_Win10_10.28.615.2018
    • N/A

    Design Document

    Total 1 Files

    No.
    Release Date
    Title、Description
    Operating System
    Document
    Download
    2024-01-29
    RITY153(Panel+Stand) system drawing
    -
    • N/A

    Manual

    Total 1 Files

    No.
    Release Date
    Title、Description
    Operating System
    Document
    Download
    2023-11-01
    RITY153 1st Quick Reference Guide
    • N/A

    Other Driver

    Total 6 Files

    No.
    Release Date
    Title、Description
    Operating System
    Document
    Download
    2023-11-01
    Intel_APL_TXE_Win10_64_3.1.65.2317_19H1
    • N/A
    2023-11-01
    Intel_APL_SerialIO_Win10_64_30.100.1750.1_19H1
    • N/A
    2023-11-01
    PenMount Windows Universal Driver V2.4.5.377 (WHQL)
    • N/A
    2023-11-01
    Quectel_LTE_Windows_USB_Driver_For_MBIM_V1.1.4
    • N/A
    2023-11-01
    Intel_APL_TXE_Win10_64_HF 3.0.11.1131 (TH2 & RS1)
    • N/A
    2023-11-01
    Intel_APL_SerialIO_Win10_64_30.100.1631.03
    • N/A

    OPEN ALL FILES
